Radial/Deep Groove Ball Bearing
- Description
- Additional information
- Reviews (0)
Description
Radial/Deep Groove Ball Bearing – Round Bore, 25 mm ID, 47 mm OD, 12 mm Width, Double Sealed, CN Internal Clearance.
- Bore Diameter: 25 mm
- Outside Diameter: 47 mm
- Overall Width: 12 mm
- Bore Type: Round
- Closure Type: Double Sealed
- Row Type and Fill Slot: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: CN
- Operating Temperature Range: -40 to 120 degree C
- Dynamic Load Capacity: 10100 N
- Static Load Capacity: 5850 N
- Precision Rating: ISO Class 0
- Finish/Coating: Uncoated
- Bearing Material: High Carbon Chrome Steel
- Cage Material: Steel
- Inner Ring Width: 12 mm
- Outer Ring Width: 12 mm
- Maximum RPM (Grease): 15000 rpm
- Fillet Radius: 0.6 mm
- Maximum RPM: 18000 RPM
Additional information
| Weight | 11 lbs |
|---|---|
| Dimensions | 10.375 × 14 × 2.125 in |
| Part Type | Bearing |
| Brand | NTN |
| Compatible Brand | NTN |
| Compatible Model | NTN |
| Product Condition | New |
